Product features:
Automatic recognition of syringe sizes (5,10,20,30 and 50/60)
Open system, and stores up to 20 editable brands
4.3 inch color touch screen, parameter setting and editing directly
Multi-function operation with 3 modes: ml/h (time,rate mode); Body-weight mode and Micro-mode
Flow rates range from 0.01 ml/h to 1,500ml/h with increment of 0.01 ml/h
KVO range from 0.01 to 5ml/h, editable
Optional wireless connection to our C7 Central Station
History record more than 5000 logs
Product features:
Uses any standard IV sets and stores up to 20 editable brands 4.3 inch color touch screen, parameter setting and editing directly.
Multi-function operation with 3 modes: ml/h (time.rate mode); Body-weight mode and Micro-mode
Electric door and anti-free flow clip patented design
Flow rates range from 0.01 ml/h to 1,200ml/h with increment of 0.01 ml/h
Double CPU for increased safety, Ultrasonic air-in-line detector
Optional wireless connection to our C7 Central Station
Historic record more than 5000 logs
9 hours battery back-up time
Features
Product Features:
Parameter setting and editing directly on touch screen
Using any standard IV sets and storing up to 200 editable brands
Resetting rate, volume, air level, occlusion level without stop infusion
5 infusion modes + Micro mode control
Infusion rates range from 0.1ml/h to 2000ml/h
Optional WIFI connection to a central monitor
Last therapy for rapid infusion start
10 hours battery back-up
IP44 waterproof
Basic Parameters:
Product Features:
Using any standard IV sets and storing up to 200 editable brands
Resetting rate, volume, air level, occlusion level without stop infusion
Infusion rates range from 0.1ml/h to 2000ml/h
Optional WIFI connection to central monitor
Last therapy for rapid infusion start
Intuitive keypad
IP44 waterproof
Specifications
4.3 inch color touch screen
Parameter setting and editing directly on screen
5 meters away at a glance
Perfect Fit
Support 2ml-60ml Syringes, more accurate and reliable
Security Protection
PBT + PC case material, corrosion resistant and easy to clean
IP44 protection level. Water and dust dose not enter.
Long Battery Life
Supports up to 10 hours of infusion, extremely long battery life, no worry about transshipment
Relay mode
Supports relay infusion between two channels, making blood concertration more stable when changing drugs
One-Handed operation
Medical staff can load the syringe with one hand for easy operation
Data sheet
Dimensions
NIBP
Method: Oscillometric Mode:
Manual, Auto, STAT
Measuring Interval in Auto Mode:
1,2,3,4,5,10,15,30,60,90,120,180,240,480 (Min)
Measuring Period in STAT Mode: 5 Min
Pulse Rate Range: 40 ~240 bpm
Alarm Type: SYS, DIA, MEAN
Measuring and Alarms Range:
Adult Mode
SYS: 40 ~240 mmHg
DIA: 10 ~ 215 mmHg
MEAN: 20 ~ 235 mmHg
Pediatric Mode
Neonatal Mode
Resolution: 1mmHg
Accuracy: Maximum Average Error ±5mmHg
Maximum Standard Deviation ±8mmHg
Overpressure Protection Adult
Mode: 297±3 mmHg
Pediatric Mode: 240±3 mmHg
Neonatal Mode: 147±3 mmHg
SpO2
Measuring Range: 0 ~ 100 %
Alarm Range: 0 ~ 100 %
Resolution: 1 %
Accuracy: 70% ~ 100% 2 %
0% ~ 69% unspecied
Actualization Interval: about 1 Sec.
Alarm Delay: 10 Sec.
Pulse Rate:
TEMP
Channel: 2
Measuring and Alarm Range: 0 ~ 50 °C
Resolution: 0.1 °C
Accuracy: ±0.2 °C
Actualization Interval: about 1 Sec.
Average Time Constant:<10 sec
IBP
Label: ART, PA, CVP, RAP, LAP, ICP, P1, P2
Measuring and Alarm Range:
Press Sensor:
Sensitivity: 5 uV/V/mmHg
Impedance: 300-3000Ω
Resolution: 1 mmHg
Accuracy: ±2% or 1mmHg which is greater
Actualization Interval: about 1 secretary
Battery: Rechargeable Li-ion battery, 14.8V 2200mAh
Standard: 3/5- Lead ECG, RESP, Spo2, NIBP,PR, TEMP
Optional: Nellcor SpO2, Mainstream/ Sidestream EtCo2, 1/2 channel IBP, Touch Screen, Thermal Recorder, Wall mount, Trolley, Central Station
LED Lights
Power Supply
Controls
Displays/Indicators
Stand
Dimensions and Weight
Unit dimensions (max height) 60cm x 55cm x155cm
Shipping (boxed) dimensions 24cm x 106cm x 68.5cm
Height Adjustment 25cm
Net Weight 15.0 kg
Shipping Weight 23.5kg
Performance Specifications
Peak Wavelength 445 to 465 nm
Light Spectrum Peak 455 nm
Lamp duration 44,000 hours at maximum temperature
Effective surface area 50cm x 30 cm
Requirements
Power Requirements Voltage: 220V AC 10%
Frequency: 47-63 Hz
Wattage: 40W
Agency Requirement ISO 13485: 2012
EN 60601-1:2006/AC 2010
EN IEN 60601-2-50:2003
Ordering Information and Servicing
MAIN UNIT ITEM ORDER NO
Colibri PT Unit CL1-1000 Main Unit
ACCESSORIES ITEM ORDER NO
Eye Patch (S) YPT-1010 Size: Small
Eye Patch (M) YPT-1011 Size: Medium Eye Patch (L) YPT-1012 Size: Large
User Manual CL-1030 English
WARRANTY
Standard Warranty 1 year Subject to MTTS policy
Piloter was built on Holo platform, which has 64-beam processing and achieve up to 5000 frames per second. Along with image fine tuning according to MSK and pain management request, Navi is able to provide not only the whole field best in detail image quality but also highlight the display of bones, muscles and nerves.
wiNeedle Intelligent Neddle Visualization Technology
The most challenging work during
procedure is always distinguishing the
needle from tissue. Navi answers this
by providing a very intelligent wiNeedle
feature. wiNeedle automatically
recognize the needle, then steer
ultrasound beam perpendicular to
needle, and enhance the needle display.
Genius Design
Piloter, in an Extremely lightweight box, equipped with a smart cart, can be anywhere with you at any time, any make sure every qualified exam and procedure is safe and efficient.
Versatile Application, Best- in class Image Quality
A wide range of transducers covers full range of general applications, from large patient to pediatrics.
An innovative middle line design along with project probe direction indicator, provide users best experience and accuracy.
Probe Button
Smart- design button on both side of probe, let user readily interact with system via gloves-on hands.
Hockey Stick Probe
A dedicated probe for small joint and superficial, with very high frequency and lightweight design, it is a perfect tool excellent detail imaging and able to be used in a limited space.
EN-D7 infusion Work Station
| Infusion Channel Range | 2,4,6,8 free style stackable |
| Applicable Models | Infusion Pump: EN-V7/ V7 Smart |
| Power management | yes |
| AC power supply | 100-240V 50/60Hz |
| Input Current | 4-2A |
| Classification | Class I |
| Water proof | IP 24 |
| Infusion channel range | 2,4,6,8 free style stackable |
| Applicable Models | Infusion Pump: EN-V7/V7 smart |
| Alarm management | yes |
| power management | yes |
| Information management | yes, can integrate with hospital HIS system |
| IrDA | yes( to supports Relay mode) |
| WiFi | Optional |
| Interface | USB, RJ45, RS232 |
| AC power supply | 100-240 50/60Hz |
| Input Current | 4-2A |
| Battery | Lithium Polymer battery 11.1V 2600m Ah |
| Classification | Class I |
| Water proof | IP24 |
In the upper range, the power can be adjusted with convenience to setup due to wide control (20 watt).
Standard 3-pin pencil and 1-pim pencil, most standard footswitching device, standard 2-pin bipolar footswitching device.
Patient Monitor KB 12A is one of the best 5 parameter monitor with optional IBP and Etco2. KB 12A has 12-inch display and KB 15A has 15-inch display with optional touch screen for easy use. With it's Lightweight and quick-hook design it is one of the top monitor in medical sector.
Prefilled ECG electrode comes in various shapes . This disposable ECG Electrode which is medically certified by necessary regulatory bodies . This electrodes are acceptable internationally .
They are widely used in industrial/ Medical oxygen concentrator in ozone production filed, Aquaculture filed for fish framing. Waste water treatment field, medical oxygen market, etc. The concentration of O2 can attain 93%±3%, having good reputation in market. Technical data refers yo below chart.
| Model | 13X-HP | 13X-HP | XTLX-01 | XTLX-02 |
Size | 0.4-0.8MM | 1.6-2.5MM | 0.4-0.8MM | 1.3-1.7MM |
Bulk Density | ≥0.62g/mL | ≥0.62g/mL | ≥0.63g/mL | ≥0.63g/mL |
Crushing Strength | / | ≥25N/piece | / | ≥15N/Piece |
Static N2Adsorption （1bar, 25°C) | ≥8mL/g | ≥8mL/g | ≥22.5mL/g | ≥22.5mL/g N2/ |
| Attrition | ≤0.3wt.% | ≤0.3wt.% | ≤0.3wt.% | ≤1.0wt.% |
Moisture Content | ≤0.5wt.% | ≤0.5wt.% | ≤0.5wt.% | ≤0.5wt.% |
Application | Medical care oxygen generator, small portable oxygen concentators of PSA system Capacity: 1L/min- 10L/min | Industrial and Medical Oxygen Generator /Plant, hospital oxygen concentrators of PSA system Capacity: 100~300Nm3/hour | Medical care oxygen generator, small portable oxyen concentrators of VPSA system Capacity: 1L/min-10L/min | Industrial and Medical Oxygen Genera tor/ Plant, hospital oxygen concentrators of PSA/VPSA system Capacity: 300- 1000Nm3/hour |
Purity | 93%+-3% | 93%+-3% | 93%+-3% | 93%+-3% |
General | Description |
Size | 295 × 218 × 279 mm (not including paddles)
295 × 218 × 323 mm (including paddles) |
Weight | Main unit (with bedrail hook) : 5 kg; Battery pack: 0.4 kg; Paddles: 0.8 kg |
Power sources | AC mains: 100 to 240 V AC (50/60 Hz); Battery: rechargeable lithium-ion
battery pack |
Defibrillator | Description |
Waveform | Biphasic truncated exponential waveform (BTE) with impedance
compensation |
Impedance range | 25 Ω ～ 200 Ω |
Energy selections | 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50, 70, 100, 150, 170, 200, 300, and 360J |
Charge time | Reach 200 J in less than 5 seconds with a new, fully charged battery;
Reach 360 J in less than 8 seconds with a new, fully charged batter |
Modes | Manual mode: asynchronous and synchronous cardioversion; AED mode |
Non-invasive Pacing | Description |
Modes | Fix and demand modes |
Waveform | Monophasic square wave pulse |
Pulse | Rate: 40ppm ~ 170ppm ±1.5%; Current: 0mA～200mA ±5% or ±5mA,
whichever is greater. |
Monitoring | Description |
Monitoring
parameters | Three curves, 3- and 5-lead ECG, SpO2, non-invasive blood pressure,
respiration, EtCO2, temperature (T1 & T2), and events. |
Network solution | Description |
Standards | Wired and 5G wireless networks |
Features:
It can be connected to the central management system. Department data synchronization management.
One-step operation, easy stacking, support relay infusion by IrDA.
It can be connected to the central management system, Department data synchronization management
Drug management system, which can save up to 5000 drugs, can be sorted by color, supports DERS.
G3 series devices are a band new generation ventilators designed by BMC. It covers CAPA, Auto CAPA, Auto Bi-Level, Bi-Level ST and ASV model as well as for sleep labs use for treatment and titration of patients with Sleep Apnea and/or Respiratory Insufficiency.
If you have trouble breathing a Bipap machine can help push air into your lungs. you wear a mask or nasal plugs that are connected to the ventilator. The machine supplies pressurized air into your airways. It's called "Positive Pressure" Because the device helps open your lungs with air Pressure...
